VTA28 for Marine
Power
565 - 815 hp
Torque
-
Certification
Non-certified
Applications
PRODUCT Detail
Overview
Specifications
Features
Brochures
421-608 kW | 565-815 hp
- Proven legacy in tough commercial marine environments, hard earned over the last 25 years
- Ideal solution for emergency or ship service power, power units, fire pumps and hydraulic units
- IMO Tier I certified and many ratings are also IMO Tier II certified
- Covered by a comprehensive one year warranty and backed by Cummins global service network
- Built at Cummins India Limited in Pune, India
Configuration | V-12 cylinder, 4-stroke diesel |
Aspiration | Turbocharged/Aftercooled |
Displacement | 28 L (1710 in3) |
Bore & Stroke | 140 x 152 mm (5.50 x 6.00 in) |
Rotation | Counterclockwise facing flywheel |
Fuel System | Pressure Time (PT) |
Product Dimensions and Weight
Overall Length | mm (in) | 1900 | (75) |
Length of Block | mm (in) |
|
|
Overall Width | mm (in) | 995 | (39) |
Overall Height | mm (in) | 1647 | (65) |
Overall Weight | kg (lb) | 2901 | (6395) |
Dimensions may vary based on selected engine configuration.
