PRODUCT Detail
746-1044 kW | 1000-1400 hp
- Building on the KTA38’s reputation hard earned on the U.S. inland rivers
- Designed to withstand the challenging conditions commercial marine operators often face; this same reliable, durable power is now available for recreational boating applications, including super yachts and yacht support vessels
- Improved idle stability and reduced noise and vibration are a direct result of the Cummins Modular Common Rail fuel system
- In-cylinder technology to meet IMO Tier II, EPA Tier 3 and EU Stg. 3a; platform for future emissions in the U.S. and globally
- Covered by a comprehensive one year warranty and backed by Cummins global service network
- Built at Daventry Engine Plant in Daventry, U.K.
Configuration | V-12 cylinder, 4-stroke diesel |
Aspiration | Turbocharged / Aftercooled |
Displacement | 38 L (2300 in³) |
Bore & Stroke | 159 X 159 mm (6.25 X 6.25 in) |
Rotation | Counterclockwise facing flywheel |
Fuel System | High Pressure Common Rail |
Product Dimensions and Weight | |||
Overall Length | mm (in) | 2282.4 | (89.86) |
Length of Block | mm (in) | 1546.9 | (60.90) |
Overall Width | mm (in) | 1573.4 | (61.95) |
Overall Height | mm (in) | 2241.8 | (88.26) |
Weight | kg (lb) | 4850 | (10,692) |
Dimensions may vary based on selected engine configuration.
Engine Design – Reliable base engine uses common components from the proven K19, K38 and K50 engines. A new cast-iron, ductile single-piece piston with nitride-coated rings and hardened cylinder liner provides excellent durability and long life
Fuel System – Modular Common Rail Fuel System features a simplified design which provides constant high injection pressure regardless of engine speed or load condition. Benefits include low noise and vibration for quiet operation, idle stability and low-end torque
Cooling System – Two-pump, two-loop, low temperature aftercooling maximizes efficiency and improves performance. Engine-mounted titanium plate heat exchanger provides superior durability with minimal maintenance requirements
Exhaust System – Dry-shielded exhaust manifold and turbocharger. Vertical or horizontal exhaust connections available for installation flexibility
Air System – Turbocharger optimized for vessel operating conditions and safety. Mounted or remote marine grade air cleaner with replaceable canister reduces maintenance cost
Lubrication System – Standard capacity 151 L (40 gal) and high capacity 204 L (54 gal) marine grade oil pan. Handed Cummins spin-on oil filters available for easy accessibility and servicing
Electronics – 24v Quantum System electronics feature an ECM to monitor operating parameters, while providing diagnostics, prognostics and complete engine protection. Simplified electrical customer interface box for all vessel connections to reduce installation complexity
Certifications – Complies with IMO Tier II, EPA Tier 3 and EU Stage IIIa emissions regulations. Designed to meet the International Association of Classification Societies (IACS) and SOLAS requirements. Consult your local Cummins professional for a complete listing of available class approvals
Optional Equipment
- C Command panels
- ELIMINATOR™ oil filtration system
- Premium coolant hose connections
- Duplex lube oil and fuel filtration
- SAE A or B (keel cooled only) accessory drives
- Front PTO adaptor
- CENTINEL oil management system
- Pre-Lube with QuickEvac
- Air or electric starter
- Rigid or flexible mounting arrangements
