Product Dimensions and Weight

Dimensions may vary based on selected engine configuration.

Engine Design – Reliable base engine uses common components from the proven K19, K38 and K50 engines. A new cast-iron, ductile single-piece piston with nitride-coated rings and hardened cylinder liner provides excellent durability and long life

Fuel System – Modular Common Rail Fuel System features a simplified design which provides constant high injection pressure regardless of engine speed or load condition. Benefits include low noise and vibration for quiet operation, idle stability and low-end torque

Cooling System – Single-loop cooling eliminates the need for two keel coolers for reduced installation expense. Engine-mounted titanium plate heat exchanger provides superior durability with minimal maintenance requirements

Exhaust System – Water-cooled exhaust manifold cools engine surface temperatures. Design is a cast single piece construction that eliminates potential exhaust leakage

Air System – Mounted or remote marine grade air cleaner with replaceable element reduces maintenance cost. Water-cooled turbocharger optimized for vessel operating conditions and safety

Lubrication System – Standard capacity 60.6 L (16 U.S. gal) shallow oil pan or high capacity 72 L (19 U.S. gal) deep oil pan for installation flexibility. Cummins spin-on oil filters available on engine service side

Electronics – 24v Quantum System electronics feature a proven CM850 ECM to monitor operating parameters, while providing diagnostics, prognostics and complete engine protection. Simplified electrical customer interface box for all vessel connections reduces installation complexity

Certifications – Complies with IMO Tier II, EPA Tier 3 and EU Stage IIIa emissions regulations. Designed to meet International Association of Classification Societies (IACS) and SOLAS requirements. Consult your local Cummins professional for a complete listing of available class approvals

Optional Equipment

• C Command panels
• ELIMINATOR™ oil filtration system
• Premium coolant hose connections
• Duplex lube oil and fuel filtration
• Integral marine gear oil cooler
• SAE A or B auxiliary drive
• Front PTO adaptor
• Fully integrated, type-approved alarm and safety system
• CENTINEL oil management system
