PRODUCT Detail
559-1119 kW | 750-1500 hp
- Proven legacy in tough commercial marine environments, hard earned over the last 25 years
- Designed to withstand the challenging conditions commercial marine operators often face; this same reliable, durable power is now available for recreational boating applications, including super yachts and yacht support vessels
- IMO Tier I certified and many ratings are also IMO Tier II certified
- Covered by a comprehensive one year warranty and backed by Cummins global service network
- Built at Daventry Engine Plant in Daventry, U.K.
Configuration | V-12 cylinder, 4-stroke diesel |
Aspiration | Turbocharged/Aftercooled |
Displacement | 38 L (2300 in3) |
Bore & Stroke | 159 x 159 mm (6.25 x 6.25 in) |
Rotation | Counterclockwise facing flywheel |
Fuel System | Pressure Time (PT) |
Product Dimensions and Weight
Overall Length | mm (in) | 2152 | (84) |
Length of Block | mm (in) |
|
|
Overall Width | mm (in) | 1462 | (58) |
Overall Height | mm (in) | 2083 | (82) |
Overall Weight | kg (lb) | 4218 | (9300) |
Dimensions may vary based on selected engine configuration.
Engine Design – Low profile for ease of installation and service. Replaceable wet cylinder liners offer longer life and lower rebuild cost. Gallery cooled pistons for maximum durability
Fuel System – Dependable Cummins PT fuel system can be operated mechanically or with CENTRY electronics for precise engine fueling. Step Timing Control (STC) allows for smooth engine acceleration under load
Cooling System – Keel cooled or engine mounted plate heat exchanger for reduced installation cost and less maintenance. Spin-on Cummins water treatment filters for protection against cooling system corrosion
Exhaust System – Dry exhaust manifold with water shielding for reduced fuel consumption and improved performance
Air System – Marine grade air filters with air inlet restriction indicator. Twin Cummins turbochargers optimized for marine usage
Lubrication System – Standard (114 L [30 gal]) or high capacity (185 L [49 gal]) marine grade oil pan. Cummins spin-on oil filter cartridge available for simplified service
Electronics – 24-volt standard electrical system with 12-volt option available. Marine grade wiring harness
Certifications – Complies with IMO Tier II emissions regulations. Certificates of compliance are available from the U.S. EPA and Lloyd’s Register of Shipping. Consult your local Cummins professional for a complete listing of current marine agency approvals for this engine
Optional Equipment
- CENTINEL™ oil management system
- C Command PT panels
- ELIMINATOR™ self-cleaning oil filtration system
- Contact your local Cummins professional for a list of optional equipment available on this engine
