PRODUCT Detail
The QSK19 meets Tier 3 and Stage IIIA emissions standards, using in-cylinder technology, a simple and cost-effective solution that maintains the proven performance, dependability and durability while operating cleanly and efficiently.
The Tier 3 approved QSK19 is a powerful example of Cummins Quantum System technology at work. In the QSK19, state-of-the-art electronic controls and Cummins modular common-rail fuel system ensure clean, efficient performance and minimum maintenance. In the same compact footprint as its predecessor.
Available in a range of ratings from 506-700 hp (377-522 kW), the QSK19 offers an impressive range of standard features. And its fuel system is tolerant to a wide variety of worldwide fuels, including high-sulfur diesel and Japanese kerosene.
To ensure that every QSK19 is perfectly matched to every piece of equipment, Cummins Advisor is ready to provide expert assistance with your installation process.
Every QSK19 engine is covered by Cummins three-step warranty, one of the most comprehensive and simplest plans in the industry.
The in-cylinder combustion technology and electronic controls of the QSK19 not only ensure clean operation that meets Tier 3 and Stage IIIA emissions standards, but also ensure powerful and efficient operation every time. With Cummins modular common-rail fuel system, injection pressure can be virtually constant at all speeds – realizing greater flexibility and precision in controlling both injection rates and timing.
Engine Type | In-Line, 4-Cycle, 6-Cylinder | |
Displacement | 1159 cu in | 19 L* |
Advertised Horsepower | 510-700 hp | 379-522 kW |
Peak Torque | 1625-2101 lb-ft | 2203-2849 N•m |
Bore and Stroke | 6.25 in x 6.25 in | 159 mm x 159 mm |
Aspiration | Air-to-Air Charge Air Cooled | |
Oil System Capacity | 80 U.S. qt | 76 L* |
Coolant Capacity** | 44 U.S. qt | 41.6 L* |
Length | 66.1 in | 1679 mm |
Width | 34.3 in | 872 mm |
Height | 63.6 in | 1616 mm |
Weight (wet) | 4,250 lb | 1,928 kg |
* L = Liters/Litres
** Engine only
Every Cummins QSK19 offers these standard features:
- Extra-Wide Gear Train – Quieter, longer lasting and capable of handling high loads with ease.
- Single-Stage Holset Turbocharger – Lower intake air temperatures provide increased air density, resulting in more power and lower emissions from less fuel.
- Full-Authority Electronics – Programmable electronic controls optimize combustion at all altitudes and conditions. Superior performance is driven by an upgraded CM850 ECM with twice the processing speed of its predecessor.
- Two-Stage Oil Filter – Combination full-flow and bypass oil filter reduces maintenance costs as it extends service intervals.
- Precision-Honed Cylinder Liners – Precise liner machining with superior metal technology creates exceptional surface smoothness and durability.
- Power Cylinder Package – Proven single-piece ferrous cast ductile iron pistons for maximum durability and reliability. This advanced design also uses nitrided liners and cast-iron top rings to handle injection pressures with exceptional durability.
- High-Durability Camshaft – Microfinishing makes it last twice as long as previous designs. Improved contact between the crosshead and rocker lever reduces wear and improves durability.
- Fleetguard® ES Filtration – Fleetguard’s ES oil filter keeps your equipment on the job with a combination full-flow and bypass design that simplifies service and reduces replacement costs.
