Whether you’re running a 60-acre family farm or an 8,000-acre spread, you need the precision and flexibility of full-authority electronic controls. That’s where Cummins 4-cylinder and 6-cylinder QSB engines make every piece of equipment work harder, longer and better.
Ratings range from 110-275 hp, with both charge air cooled and turbocharged versions that deliver strong performance at every start. A low-maintenance filter assembly is just one of many standard features that minimize downtime for maintenance. Among the many options that let you customize your QSB are packages that reduce the overall noise level by as much as 4 dBA.
Getting the right combination to match your equipment, environment and workloads has never been easier. Cummins PowerMatch and Advisor are ready to provide expert assistance with your spec’ing and installation process.
Every QSB engine is covered by Cummins three-step warranty, one of the most comprehensive and simplest plans in the industry.
QSB engines meet every Tier 2 and Stage II emissions standard and will achieve Tier 3 and Stage IIIA compliance with in-cylinder technology that maintains a compact, simple and cost-effective design solution.
The QSB engine is not available for purchase anymore.
Cummins QSB engines are built on one of the most successful engine block designs in the world. Available in 3.9-, 4.5- and 5.9-liter sizes, and a choice of 12- or 24-valve configuration in the 6-cylinder models, there’s a QSB engine with the right size, horsepower and torque to fit every type of agricultural equipment from small tractors to fruit tree shakers and berry pickers.
QSB3.9 | QSB4.5 | QSB5.9 | |
Engine Type | In-Line, 4-Cylinder | In-Line, 4-Cylinder | In-Line, 6-Cylinder |
Displacement | 238 cu in3.9 liters | 275 cu in4.5 liters | 359 cu in5.9 liters |
Advertised Horsepower | 120-130 hp89-97 kW | 110 hp82 kW | 130-275 hp97-205 kW |
Peak Torque | 350-355 lb-ft475-481 N•m | 305 lb-ft414 N•m | 400-730 lb-ft542-990 N•m |
Bore and Stroke | 4.02 in x 4.75 in102 mm x 120 mm | 4.02 in x 5.39 in102 mm x 137 mm | 4.02 in x 4.72 in102 mm x 120 mm |
Aspiration | Turbocharged and Charge Air Cooled | ||
Oil System Capacity | 10 U.S. qt9.5 liters | 10 U.S. qt9.5 liters | 17 U.S. qt16.1 liters |
Coolant Capacity | 8.3 U.S. qt7.9 liters | 8.3 U.S. qt102 mm x 120 mm | 10.5 U.S. qt9.9 liters |
Length | 30.6 in777 mm | 30.6 in777 mm | 40.0 in1017 mm |
Width | 24.9 in632 mm | 24.9 in632 mm | 26.9 in684 mm |
Height | 37.7 in958 mm | 35.5 in901 mm | 37.7 in958 mm |
Weight (Wet) | 745 lb338 kg | 745 lb338 kg | 952-1056 lb432-479 kg |
The QSB features a cast-iron parent bore block structurally designed to reduce noise and increase durability. An integrated water pump, lube pump, and cooler housings and coolant bypass eliminate possible leak points.
- Full-Authority Electronic Controls – Optimize engine performance and provide seamless integration with other components, advanced diagnostics, plus a complete set of programming options.
- A Deep, Stiff Crankcase With Structural Ribs – For lower noise and increased life.
- Wastegated HX35 Turbocharger – Wastegated design optimizes operation across the torque curve with improved response.
- Low-Maintenance Fuel Filter Assembly – The fuel filter incorporates an integral water separator and water-in-fuel sensor. 500-hour filter life with easy top-load replacement using standard Fleetguard® filters.
- Centered Injectors With Symmetrical Piston Bowls – For improved airflow and even fuel dispersion, resulting in increased power, improved transient response and reduced fuel consumption on 24-valve versions of the QSB.
