• Factory-Built, Dedicated Natural Gas Engine – manufactured by Cummins on the same assembly line as Cummins diesels, the L9N shares many components and parts with Cummins L Series diesels, inheriting their renowned simplicity.
• Heavy-Duty Design – rugged features include replaceable wet liners, roller followers, by-pass oil filtration and targeted piston cooling for longer service in the toughest work environments.
• Fuel Capability – the L9N is capable of operating on compressed or liquefied natural gas (CNG, LNG). The L9N can also operate on up to 100 percent biomethane, renewable natural gas made from biogas or landfill gas that has been upgraded to pipeline and vehicle fuel quality.
• Air/Fuel Regulation – Cummins closed-loop electronic control system with sensors for engine parameters, including intake manifold pressure and temperature, fuel inlet pressure, knock detection, air/fuel ratio and fuel mass flow.
• High Power and Torque – available up to 320ps with 1356 Nm of torque for alternative fuel truck and bus applications.
• Closed crankcase ventilation (CCV) – new remote mounted system required to re-cycle blow-by gases now counted in the engine emissions.
• Cummins Wastegated Turbocharger – developed by Cummins Turbo Technologies with electronic control for precise air handling. Has a water-cooled bearing housing for durability.
• Air Intake System – charge air cooling reduces emissions by lowering intake manifold air temperatures.
• Maintenance-Free Aftertreatment – uses a Three-Way Catalyst (3WC) aftertreatment. 3WCs are effective, simple, passive devices, packaged as part of the muffler, that provide consistent emissions control performance and are maintenance-free. The L9N does not require active aftertreatment such as a Diesel Particulate Filter (DPF) or Selective Catalytic Reduction (SCR).
• High-Energy Ignition System – spark ignited system providing better performance and longer service intervals with improved spark-plug and coil durability.
• High-Efficiency Lube Cooler – lowers oil temperatures for longer engine life.
• Accessory Belt Drive System – self-tensioning serpentine polyvee belt accessory drive system for water pump, engine-mounted fan hub and most alternators. Gear-driven air compressor with provision for gear-driven hydraulic pump.
• Crankshaft – eight counterweight, fully balanced, hightensile- strength steel forging with induction hardened fillets and journals, for outstanding durability.
• Control System – full drive-by-wire. Electronic Control Module (ECM) provides full monitoring and control of the engine sensors, fuel system and ignition system. Full interface capability to Cummins INSITE and diagnostic service tools.
• Oil Filter – the combination full-flow and bypass oil filter improves filtration while minimizing oil filter replacement and disposal costs.
• Global Support – backed by the widest network in the industry, with over 5,000 service outlets worldwide.
