General Specifications
Inline 6-Cylinder, 4-Cycle, Natural Gas

* Rating dependent
** Weight is approximate and varies with options.

World-class Features and Benefits

Engine Controls

Factory integration of the Murphy Engine Integrated Control System (EICS™) unites the functionality of the ignition, air/fuel ratio controller and speed governor into a single engine control module.

Base Engine

Cylinder heads are designed for optimal intake air/ exhaust flow. Pyromet^® exhaust valves with thermal barrier coating and Tribaloy^® T400 intake valves add durability. The G855GCE and the GTA855GCE come with a 1-year/unlimited-hours warranty.

Flywheel and Flywheel Housing

SAE #1, cast iron, machined to accommodate starter mounting.

Power Take-Off (PTO)

Multiple front drive options are offered for driving the compressor cooler fan.

Air Handling

The GTA855GCE’s turbocharger design delivers maximum performance and life. It includes a factory-installed heavy-duty two-stage air cleaner w/safety element.

Starting System

The standard system features a robust Delco Remy^® 39MT 24-volt starter with SAE #3 mounting flanges. An air/gas starter is optional.

Electrical System

Includes a 24-volt alternator.

Lubrication

The deep, full-length, high-capacity oil pan allows for extended drain intervals. Combo full-flow and bypass oil filters reduce maintenance costs while extending service intervals.

Cooling System

A two-pump, two-loop cooling system effectively separates the aftercooler and jacket water coolant circuits to maintain lower intake manifold temperatures and provide capability for higher power ratings. Integrated coolant filters add corrosion protection for the jacket water circuit.

Exhaust System

The water-cooled manifold reduce surface and exhaust gas temperatures.

Ignition System

EICS capacitive discharge ignition with smart-coil technology provides reliable spark and individual cylinder diagnostics and knock sensing capabilities.

Air/Fuel Control

Direct-acting electronic pressure regulator assemblies controlled by engine specific calibration provides reliable emissions control.

Speed Control

Integrated electronic governor provide stable RPM control with optional input to monitor and control suction or discharge pressure.

Emissions System

Optional, customer supplied, three-way catalyst (TWC) emissions package meets federal and local emissions requirements.
